Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 2:
General operation
2461-901-01 A/November 2015 2-23
Source Settings menu
You can change the following settings by pressing the MENU key and selecting Source Settings.
Setting Description
Source Range
Set the source range for the selected source function. For more
information, see Source range (on page 2-124).
Output Off
Select from Hi Impedance, Normal, Zero, and Guard output-off
states. For more information, see Output-off state (on page 2-97).
Overvoltage
Protection Limit
Set the overvoltage protection setting of the source output to
restrict the maximum voltage level that the instrument can source.
For more information, see Overvoltage protection (on page 2-121).
High Capacitance
Turn on this setting to minimize overshoot, ringing, and instability
when measuring low current while driving a capacitive load. For
more information, see High-capacitance operation (on page 4-22).
Source Readback
Turn on this setting to have the instrument record and display the
actual value of the source, instead of the programmed value. Using
source readback results in more accurate measurements, at the
cost of a reduction in measurement speed. Turn off this setting to
increase measurement speed. For more information, see Source
readback (on page 2-130).
Source Delay
Set a delay for the selected source function. This delay is in
addition to normal settling times. Select Auto Delay to have the
instrument automatically set the delay, or select Specify Delay to
enter a value. For more information, see Setting the source delay
(on page 2-131).

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
