Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2461-901-01 A/November 2015 6-123
Example
*RST
*CLS
DIG:FUNC "CURR"
DIG:CURR:RANG 10e-3
DIG:CURR:SRAT 25000
SOUR:FUNC VOLT
SOUR:VOLT:READ:BACK ON
SOUR:PULS:TR:VOLT 1e-3, 3e-3, 10e-3, 3, ON, "defbuffer1", 0, 90e-3, 5e-3, 5e-3
INIT
*WAI
Reset the instrument to its default settings and clear event registers and queues. Set the digitize function to
current and the digitize sample rate to 25,000 readings per second. Set the source function to voltage
and turn
source readback on.
Set up a pulse train with a bias level of 1 mV and a pulse level of 3 mV. Enable measurements and save
readings in defbuffer1. Set the delay to zero and the off time to 90 ms. Set the pulse voltage limit and the
bias voltage limit to 5 mV.
Start the pulse train and wait for it to execute.
Also see
Operating boundaries (on page 4-4)
Pulse operation (on page 3-64)
:SOURce[1]:PULSe:SWEep:<function>:LIST (on page 6-116)
Trigger model (on page 3-107)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
