Measure Config Lists menu
The Config Lists menu allows you to select an existing measure configuration list,
create a new list, load configuration settings to and from the instrument (system), and
view the settings of an index in a configuration list. For more information about using
configuration lists, see Configuration lists (on page 3-30).
Setting Description
Select List
Displays a list of available configuration lists from which you can
choose. If you selected Source on the main menu, a menu of the
source configuration lists presently available on the instrument is
displayed.
If you selected Measure on the main menu, a menu of the
measure configuration lists presently available on the instrument is
displayed.
New List
Creates a new, empty configuration list. To populate the list with
the present instrument settings, select System to Index.
Delete Index
Deletes a configuration list index from the selected configuration
list.
System to Index
Saves the present instrument settings to an index at the end of the
selected configuration list.
Index to System
Restores the instrument to the settings stored in the selected
configuration list index.
Index Details
Displays the details of the selected configuration index. Details
include settings such as function, value, delay, calculations, and
range. You can scroll the displayed list to view additional settings.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
