Model 2461

Interactive SourceMeter® Instrument Reference Manual Section 6:

SCPI command reference

2461-901-01 A/November 2015 6-223

Example

*RST

:SOURce:CONF:LIST:CRE "SOURCE_LIST"

:SENS:CONF:LIST:CRE "MEASURE_LIST"

:SOUR:VOLT 1

:SOURce:CONF:LIST:STORE "SOURCE_LIST"

:SENS:CURR:RANG 1e-3

:SENSe:CONF:LIST:STOR "MEASURE_LIST"

:SOUR:VOLT 5

:SOURce:CONF:LIST:STORE "SOURCE_LIST"

:SENS:CURR:RANG 10e-3

:SENSe:CONF:LIST:STOR "MEASURE_LIST"

:SOUR:VOLT 10

:SOURce:CONF:LIST:STORE "SOURCE_LIST"

:SENS:CURR:RANG 100e-3

:SENSe:CONF:LIST:STOR "MEASURE_LIST"

:TRIG:LOAD "ConfigList", "MEASURE_LIST", "SOURCE_LIST"

INIT

Set up a source configuration list named SOURCE_LIST and a measurement configuration list named

MEASURE_LIST.

Create the source list with three indexes that set the source voltage levels to 1, 5, and 10.

Create the measure list with three indexes that set the measure current ranges to 1 mA, 10 mA, and

100 mA.

Load the configuration list trigger model, using these two configuration lists. Start the trigger model.

Also see

None
