7: Introduction to TSP operation Model 2461 Interactive SourceMeter® Instrument
7-10 2461-901-01 A/November 2015
Power up script
The power up script runs automatically when the instrument is powered on. To create a power up
script, save a new script and name it autoexec. The autoexec script is automatically saved to
nonvolatile memory. See Saving a script to nonvolatile memory (on page 7-8).
If an autoexec script already exists, you must delete it by sending the
script.delete("autoexec") command. Performing a system reset does not delete the
autoexec script.
To set up the power up script from the front panel:
1. Press the MENU key.
2. Under Scripts, select Run.
3. Select Copy to Power Up. A dialog box confirms that the script was copied.
4. Select OK.
To save the power up script using remote commands:
Send the command:
autoexec.save()
To delete the existing autoexec script, send the command:
script.delete("autoexec")
Commands that cannot be used in scripts
You cannot use the following commands as variables in scripts:
There are some functions that resemble some of the strings below, but are actually defined TSP
functions. For example, printbuffer() (on page 8-93) is a function you can use in scripts. If you are
uncertain, check the TSP command reference (on page 8-1) to verify that the string is part of a
defined function.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
