SMU source commands are:
smu.source.autorange (on page 8-175)
smu.source.autodelay (on page 8-176)
smu.source.configlist.catalog() (on page 8-177)
smu.source.configlist.create() (on page 8-177)
smu.source.configlist.delete() (on page 8-178)
smu.source.configlist.query() (on page 8-179)
smu.source.configlist.recall() (on page 8-180)
smu.source.configlist.size() (on page 8-181)
smu.source.configlist.store() (on page 8-182)
smu.source.delay (on page 8-183)
smu.source.func (on page 8-184)
smu.source.highc (on page 8-184)
smu.source.level (on page 8-185)
smu.source.offmode (on page 8-186)
smu.source.output (on page 8-188)
smu.source.protect.level (on page 8-188)
smu.source.protect.tripped (on page 8-189)
smu.source.range (on page 8-207)
smu.source.readback (on page 8-208)
smu.source.sweeplinear() (on page 8-210)
smu.source.sweeplinearstep() (on page 8-212)
smu.source.sweeplist() (on page 8-214)
smu.source.sweeplog() (on page 8-216)
smu.source.userdelay[N] (on page 8-218)
smu.source.xlimit.level (on page 8-219)
smu.source.xlimit.tripped (on page 8-220)
SMU digitize commands
smu.digitize.aperture (on page 8-106)
smu.digitize.count (on page 8-107)
smu.digitize.displaydigits (on page 8-107)
smu.digitize.func (on page 8-108)
smu.digitize.limit[Y].audible (on page 8-109)
smu.digitize.limit[Y].autoclear (on page 8-110)
smu.digitize.limit[Y].clear() (on page 8-110)
smu.digitize.limit[Y].enable (on page 8-111)
smu.digitize.limit[Y].fail (on page 8-113)
smu.digitize.limit[Y].high.value (on page 8-115)
smu.digitize.limit[Y].low.value (on page 8-116)
smu.digitize.math.enable (on page 8-119)
smu.digitize.math.format (on page 8-120)
smu.digitize.math.mxb.bfactor (on page 8-121)
smu.digitize.math.mxb.mfactor (on page 8-122)
smu.digitize.math.percent (on page 8-123)
smu.digitize.range (on page 8-118)
smu.digitize.read() (on page 8-124)
smu.digitize.readwithtime() (on page 8-125)
smu.digitize.rel.acquire() (on page 8-126)
smu.digitize.rel.enable (on page 8-127)
smu.digitize.rel.level (on page 8-127)
smu.digitize.samplerate (on page 8-128)
smu.digitize.unit (on page 8-129)
smu.digitize.userdelay[N] (on page 8-130)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
