Keithley 2461 Reference Manual

Section
8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
8-34 2461-901-01 A/November 2015
The values returned by this command depend on the source readback state:
• If readback is off, the value is the programmed value
• If readback is on, the value is the actual measured source value
Example
reset()
testData = buffer.make(50)
smu.source.func = smu.FUNC_DC_CURRENT
smu.source.level = 1e-6
smu.source.output = smu.ON
trigger.model.load("SimpleLoop", 3, 0, testData)
trigger.model.initiate()
waitcomplete()
printbuffer(1, 3, testData.sourcevalues)
Create a reading buffer named
testData, configure the instrument to
make three measurements, and store
the readings in the buffer.
Set the source value to 1e-6 A.
Print the source values being output
when readings in the reading buffer
were acquired.
Example output:
9.9999874692e-07,
1.0000017028e-06,
1.0000054544e-06
Also see
bufferVar.sourcestatuses (on page 8-31)
bufferVar.sourceunits (on page 8-32)
bufferVar.statuses (on page 8-36)
bufferVar.formattedreadings (on page 8-23)
buffer.delete() (on page 8-11)
buffer.make() (on page 8-14)
bufferVar.clear() (on page 8-19)
print() (on page 8-92)
printbuffer() (on page 8-93)
Reading buffers (on page 3-2)
Remote buffer operation (on page 3-23)
smu.source.readback (on page 8-208)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
