Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-193
Example
smu.source.func = smu.FUNC_DC_VOLTAGE
smu.source.pulse.ilimit.level = 1
print(smu.source.pulse.ilimit.level)
Set the source function to voltage with the pulse current limit set to 1 A.
Query the source pulse current limit setting.
Output:
1
Indicates that the source pulse current limit is 1 A.
Also see
Pulse operation (on page 3-64)
smu.source.xlimit.level (on page 8-219)
smu.source.xlimit.tripped (on page 8-220)
Trigger model (on page 3-107)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
