Korg Kronos User Manual

Appendices
274
General Disk Mode Load, save, utility, audio CD burning, audio CD playback, data filer function (save/load MIDI System
Exclusive data), CD-R/RW (UDF format read/write), ISO9660 Level 1
Controllers Vector joystick, joystick, ribbon controller, switches 1 & 2
Control Surface Control Assign Switches: Assigns the Control Surface to Timber/Track, Audio,
External, Realtime Knobs/KARMA, Tone Adjust/EQ
Mixer Knobs Switch: Assigns the Mixer Knobs to either Channel Strip or
Individual Pan, Reset Control Switch, Solo Switch, Knobs 1-8, Switches 1-8
(Upper Row), Switches 1-8 (Lower Row), Sliders 1-8, Master Slider
KARMA Control: On/Off, Latch, Chord Assign, Module Control
KARMA Controller
Section
Switches = ON/OFF, LATCH, MODULE CONTROL
DRUM TRACK
Controller Section
Switches = ON/OFF
Display TouchView graphical user interface, 8 inch TFT, SVGA (800x600 dots), adjustable brightness.
Principal specifications Frequency response 20 Hz–22 kHz ±1.0 dB, 10 k
Ω load
THD+N 20 Hz–22 kHz 0.01 %, 10 k
Ω load (typical)
Signal to noise ratio 95 dB (typical)
Dynamic range 95 dB (typical)
Crosstalk 95 dB, at 1 kHz (typical)
Audio Outputs (Analog)
(Digital)
AUDIO OUTPUT
(MAIN) L/MONO, R
AUDIO OUTPUT
(INDIVIDUAL) 1–4
1/4” TRS balanced
Output Impedance: 350
Ω stereo; 175 Ω mono (L/Mono only)
Nominal Level: +4.0 dBu
Maximum Level: +16.0 dBu
Load Impedance: 600
Ω or greater
MAIN VOLUME knob controls only AUDIO OUTPUT (MAIN) L/MONO and R
Headphones 1/4” stereo phone jack
Output Impedance: 33
Ω
Maximum Level: 60+60 mW @33 Ω
MAIN VOLUME knob (link with AUDIO OUTPUT (MAIN))
Optical S/P DIF Format: 24 bit, S/P DIF IEC60958 EIAJCP-1201
Sample Rate: 48 kHz
Digital output of the same signals as AUDIO OUTPUT (MAIN) L/MONO and R
USB B Format: 24 bit
Sample Rate: 48 kHz
2 channels (Digital output of the same signals as AUDIO OUTPUT (MAIN)
L/MONO and R)
Audio Inputs (Analog)
(Digital)
Audio inputs 1, 2 1/4” TRS balanced
MIC/LINE input level switches, LEVEL knobs
Input Impedance: 10 k
Ω
Nominal Level: LINE
+4 dBu (LEVEL knob = min), –36 dBu (LEVEL knob = max)
Nominal Level: MIC
–22 dBu (LEVEL knob = min), –62 dBu (LEVEL knob = max)
Maximum Level: LINE
+16 dBu (LEVEL knob = min), –24 dBu (LEVEL knob = max)
Maximum Level: MIC
–10 dBu (LEVEL knob = min), –50 dBu (LEVEL knob = max)
Source Impedance: 600
Ω
Signal to noise ratio: 95 dB (typical)
Dynamic range: 95 dB (typical)
Crosstalk: 95 dB, at 1 kHz (typical)
Optical S/P DIF Format: 24 bit, S/P DIF IEC60958 EIAJCP-1201
Sample Rate: 48 kHz
USB B Format: 24 bit
Sample Rate: 48 kHz
2 channels
Control Inputs DAMPER (half damper supported)
ASSIGNABLE SWITCH, ASSIGNABLE PEDAL
MIDI IN, OUT, THRU
USB USB A (TYPE A) x 2 For connection to external USB MIDI and storage devices
USB B (TYPE B) x 1 MIDI/audio interface
MIDI: 1 (16 channel) input / 1 (16 channel) output
Audio: 2 channel input / 2 channel output
2 USB 2.0 High-Speed ports (supports 480 Mbps)
Disk Drive KRONOS: 30 GB SSD (2.5"); KRONOS X: 62 GB SSD (2.5”); optional installation of second internal SSD
Power AC Power Supply terminal, POWER On/Off switch

Korg Kronos Specifications

Operating Environment

operating temperature range	+5 – +35 °C

Power

power consumption	60 W

Weight and Dimensions

dimensions (61 keys)	1052 x 362 x 134 mm
dimensions (73 keys)	1243 x 411 x 145 mm
dimensions (88 keys)	1455 x 411 x 145 mm
weight (61 keys)	12.5 kg
weight (73 keys)	20.3 kg
weight (88 keys)	23.0 kg
