2WA/2NJ/2RK-1
8-56
YC11 4 EXIT_FAN_REM O DC0V/24V Right front eject fan motor 1: On/Off
5 +24V2 O DC24V DC24V power output to Right front eject
fan motor 1
6 EXIT_FAN_REM O DC0V/24V Right rear eject fan motor 1: On/Off
7 +24V2 O DC24V DC24V power output to Right rear eject
fan motor 1
8 +24V2 - - Not used
9 DU_CL_UPPER_
REM
-- Not used
YC12 1 GND - - Ground
2 GND - - Ground
3 MPF_TABLE O DC0V/3.3V MP tray switch: On/Off
4 MPF_WID1 O DC0V/3.3V MP paper width sensor: On/Off
5 MPF_WID2 O DC0V/3.3V MP paper width sensor: On/Off
6 MPF_WID3 O DC0V/3.3V MP paper width sensor: On/Off
7 MPF_LNG O DC0V/3.3V MP paper length sensor: On/Off
8 LED_+3.3V3 I DC3.3V DC3.3V power input from Feed PWB
9 MPF_PPR_SET O DC0V/3.3V MP paper sensor: On/Off
10 MPF_LIFT_UP_S
ENS
O DC0V/3.3V MP upper lift sensor: On/Off
11 MPF_LIFT_DOW
N_SENS
O DC0V/3.3V MP lower lift sensor: On/Off
12 MPF_JAM_SENS O DC0V/3.3V MP paper feed sensor: On/Off
13 MPF_CL_REM I DC0V/24V MP paper feed clutch: On/Off
14 +24V2 I DC24V DC24V power input from Feed PWB
15 MPF_LIFT_MOT_
A
I DC0V/24V MP lift motor: On/Off
16 MPF_LIFT_MOT_
B
I DC0V/24V MP lift motor: On/Off
17 +24V2 I DC24V DC24V power input from Feed PWB
18 ID_SOL_ACT I DC0V/24V CLSOL: On/Off
19 GND - - Ground
20 GND - - Ground
YC13 1 +3.3V2_ID I DC3.3V DC3.3V power input from Feed PWB
2 LOOP_SENS O DC0V/3.3V Loop sensor: On/Off
3 EDGE_FAN_REM I DC0V/24V Right eject fan motor 2: On/Off
4 DU1_A I DC0V/24V(pulse) DU motor 1 drive control signal
5 DU1_B I DC0V/24V(pulse) Duplex motor 1 drive control signal
6 DU1_A/ I DC0V/24V(pulse) Duplex motor 1 drive control signal
Connec-
tor
Pin Signal I/O Voltage Description
