2WA/2NJ/2RK-1
6-107
Description
Displays and sets the control voltage specification of the IH PWB.
Purpose
Execute to check the control voltage specification
* :When U021 is executed, set to the same voltage specification as the IH PWB.
Execution
1.Press the [Start] key.
2.Select the item to set.
* : Not used for this model
Setting: Set Fuser
1.Change the setting value by using [+] [-] key or the numeric keypad.
2.Press the [Start] key and then fix the setting.
Setting: CT Mode
1.Select the item to set.
2.Press the [Start] key and then fix the setting.
Completion
Press the [Stop] key.
* :The screen for selecting a maintenance item No. is displayed.
U169 Setting the fuser power source
(Message: Set Fuser Power Source)
Items Contents
Set Fuser Set fuser unit destination
CT Mode* Current sensor mode setting
Items Contents Setting range Initial setting
Mode Set the fuser unit destination 1: 100V specifi-
cations
2: 200V specifi-
cations
3: 120V specifi-
cations
4: 110V specifi-
cations
-
(Destination)
Items Contents
On Current sensor mode setting On
Off Current sensor mode setting Off
