7 How to Work with the Analyser
7.9 SIngle Measurement
LAR | PROCESS ANALYSERS AG
Vessel:
With this function, the vessel can be selected, from which the sample is taken for individual measure-
ment.
Archive:
Via the archive the results of all individual measurements can be viewed.
7.9.1.1 Archive
In this view, past individual measurements can be viewed. Click on one of the measured values to get
to the single view.
7.9.1.2 Single Measurement - Single view
In this view, the measurement result in mg / l and FSR x sec can be seen on the left side and the peak
curve of the detector on the right side.
About 200 signal curves are stored. For results that were previously detected, no more curves are dis-
played.
Fig. 95: Single measurement - Archive (Example)
Notice
Using the search function, individual measurements can be found faster.
i
