7.15.2.2 Red Fault Codes
With red fault codes, it is necessary to eliminate the fault as quickly as possible, since the measuring
operation is stopped.
The table below shows all red fault codes:
Table 16: Red fault codes
Fault Code Description Solution
E211 - E214 Detector defective / missing • Contact support
E1650 Error opening the Auto-TIC port • Contact support
E1660 Error closing the Auto-TIC port • Contact support
E1700 Injection needle repeatedly did not hit
the position
• Check XY axis
• Check needle grommet
• Check positions
E1710 Injection needle does not hit X position • Check XY axis
• Check needle grommet
• Check positions
E1720 Injection needle does not hit Y position • Check XY axis
• Check needle grommet
• Check positions
E1730 Injection needle does not hit Z position • Check XY axis
• Check needle grommet
• Check positions
E1810 Furnace emergency shutdown
(Max. temperatur exceeded)
• Contact support
E1811 Furnace room monitoring • Contact support
E1812 Furnace room monitoring • Contact support
E1815 Cooler temperature not reached • Wait until temperature has been
reached
E1820 Furnace temperature not reachedt • Wait until temperature has been
reached
E1821 Error opening / closing the injection
ports
• Contact support
E1823 Needle sensor defective • Contact support
E1831 Limit "humidity" exceeded • Check humidity
• Contact support
E1833 Pressure too high (> 600 mbar) • Check reactor pipe
