11.1 Device Specifications
Notice
All graphic, electronic or mechanical changes intended for technical progress
are reserved.
Table 35: Device Specifications
Type Dimensions / Description
Casing Splash-proof steel housing
Ex-type Explosion-proof IECEx overpressure enclosure with flushing
Dimensions
ca. 1.078 x 1.060 x 635 mm
Casing volume 1 Channel 300 l
6 Channels 360 l
Weight ca 180 kg
Mains voltage
(Note information on rating plate)
115/230 V/AC, 50/60Hz
Fusing min. 16A (K-characteristics)
Power input ca. 1,2 KW
Signal outputs Numer: Depending on configuration 2 - 33 analog outputs
Warning: Each analog output is galvanically isolated from
the other analog outputs and the analog outputs are galvani-
cally isolated from the housing.
0 – 20mA or 4 – 20mA
max. load 500 Ohm
Interface serial interface RS 232
Noise levell max. 70 dB
Potential-free contactors 8 programmable relays (NO or NC)
Voltage: max. 24 V=, 24V~
Amperage: max. 1 A=, 1A~
USB interface USB 2,0
Display 10,4“ resistive Touchscreen, TFT Display
Carrier gas consumption Standard: ca. l/h (Nitrogen 5.0)
External air supply (optional) Dew point max. -5°C
Digital inputs 8
