76 Instruction Manual QuickTOC

ultra

IECEx 12E5119

5 Start-up

5.16 Perform a Test-Run LAR | PROCESS ANALYSERS AG

5.16 Perform a Test-Run

A test run must be performed to check whether the injection needle hits all positions correctly (furnace

and vessels). Follow the instructions in Chapter 7.8.3 from page 120 to perform a test run.

5.17 Rinse the Injection System und Sample Tubes

Proceed as follows:

1. Switch to the “Service Action” display (Chapter 7.8.2 from page 118).

2. Rinse the injection system using the “Rinse injection system” function.

3. Rinse the sample tubes using the “Rinse sample tubes” function.

5.18 Costumisation of Application-Specific Settings

Application-specific hardware and parameter changes can be set.

Change the following settings:

• Measurement Parameters (Chapter 7.7.1 from page 101)

• Measurement Channels (Chapter 7.7.2 on page 105)

• Relays (Chapter 7.7.3 from page 108)

• Analog Outputs (Chapter 7.8.5 on page 124)

5.19 Checking Status Parameters

The status parameters on the Status screen must be checked to ensure perfect operation of the analys-

er. Use for the check the start-up log (Tab. 7, page 58), in which all relevant status parameters are re-

corded with associated status information permitted. The status parameters are on the “Status screen”

display (Chapter 7.1.4 from page 91).

Notice

If the injection needle does not pierce the vessels correctly, the X position

must be corrected manually from the “Test run” display (Chapter 7.8.3 from

page 120).

If you have any question, please contact your local partner or the Technical

Support of LAR (Chapter 15 on page 283).

Notice

Before the first measurement, the injection system and sample tubes must be rinsed.
