4 Installation

4.1 Installation process LAR | PROCESS ANALYSERS AG

4.1.2 Installation of Optional Accessories

• Installation of the Reagent Cabinet (Chapter 9.2.2 from page 207)

• Installation of the FlowSampler

(Chapter 9.3.4 from page 221)

Notice

Careful documentation is a precondition for any guarantee and warranty

claims.

If you have any questionto the installations, please contact your local partner

or the Technical Support of LAR (Chapter 15 on page 283).
