118 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
7 How to Work with the Analyser
7.8 Service LAR | PROCESS ANALYSERS AG
7.8.2 Service Actions
Furnace:
This function can be used to switch the oven on and off.
Injection port:
This function allows the oven valve to be opened and closed.
Condensate pump:
This function can be used to switch the condensate pump on and off.
Stirrer:
This function allows all stirrers to be switched on and off together.
Rinse sample tubes:
To prepare a measurement procedure, the sample tubes and reservoirs can be rinsed with the sample.
To do this, select a sample stream and set the sample purging time.
Warning
To perform the service actions, the analyser must be in offline mode (offline
button). This will stop all measurements.
Fig. 82: Service Actions (Example)
Notice
The heating time of the oven is approx. 120 min. This corresponds to a heating
rate of 10 ° C / min. This time is permanently configured and can not be
changed.
!
i
