11.2 Ambient conditions
11.3 Specifications for Accessories and Options
Table 36: Ambient conditionsAmbient conditions
Type Dimensions / Description
Temperature min. 5°C - max. 35°C
Humidity max. 80%
Dimensions (wall mounting min. 1.030 x 1.760 x 1.210 mm
Mounting dimensions (LAR moun-
ting rack)
min. 1.070 x 2.000 x 1.440 mm
Table 37: Specifications for accessoories and options
Type Dimensions / Description
Carrier gas purification ca. 630 x 500 x 100 mm
LAR mounting rack ca. 1.000 x 2.000 x 815 mm
Weight: ca.65 kg
Reagent closet ca. 500 x 500 x 300 mm
space for 3x 5l canisters
FlowSamplers
• FlowSampler
®
mounting plate:
ca. 400 x 500 x 120mm
• FlowSampler
®
mounting plate , 2 sample streams
ca. 400 x 500 x 240 mm
