8 Care and Maintenance
8.7 Perform Maintenance Actions
LAR | PROCESS ANALYSERS AG
8.7.9 Replace Acid Trap Filling
Preconditions: - Up to 2/3 of the brass wool has a red-brown discolouration.
- The zinc is up to 2/3 matt.
1. Use a screwdriver to open the pipe clamps.
2. Take the tubes to the acid trap.
3. Take the acid trap from the holder.
4. Remove the contents of the acid trap.
5. Fill the quartz wool into the acid trip carefully because otherwise the quartz wool becomes
pulverised and a blockage of the gas paths is created when it is stuffed by too much (bottom).
6. Fill the zinc into the acid trap (middle).
7. Fill the brass wool into the acid trap (top). No brass wool may be protruding.
8. Check the order (from the bottom up): Quartz wool, zinc, brass wool.
9. Fit the filled acid trip into its holder.
10. Reconnect the tubes to the acid trap.
8.7.10 Replace Acid Trap
Preconditions: - Up to 2/3 of the brass wool has a red-brown discolouration.
- The zinc is up to 2/3 matt.
1. Use a screwdriver to open the pipe clamps.
2. Take the tubes to the acid trap.
3. Remove the acid trap from the holder.
4. Fit the new acid trip into its holder.
5. Connect the tubes to the acid trap.
Danger
Corrosive chemicals
The acid trap is filled with highly corrosive material.
Use gloves and respiratory protection when working on the acid trap
Notice
LAR offers filled acid traps for simple and quick maintenance.
If you have any question, please contact the Sales Department of LAR
(Chapter 15.1 on page 283).
