9 Accessories and Options
9.4 Overflow Sampler
LAR | PROCESS ANALYSERS AG
9.4.6.1 Clean Overflow Sampler
Precondition: - Overflow sampler is contaminated.
1. Loosen the four knurled screws (1).
2. Remove the cover (2).
3. Pull off the overflow plug. The contents of the overflow sampler are draining downwards.
3. Clean the overflow sampler thoroughly with water.
4. Insert the overflow plug back into the drain opening.
5. Attach the lid (2) with the four knurled screws (1).
1
Knurled screws
2 Lid
Abb. 146: Clean overflow sampler
1
2
