LAR Process Analysers QuickTOC ultra - TIC-Stripping Vessel (3 Months)

168 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
8 Care and Maintenance
8.3 Performing the Visual Inspections LAR | PROCESS ANALYSERS AG
8.3.9 TIC-Stripping Vessel
1. Check the cleanliness of the TIC stripping vessel. If contamination is ascertained, cleaning is nec-
essary (Chapter 8.5.11 on page 176).
2. Once the test criterion is met, proceed with the next step.
Notice
We recommend storing each individual glass component in order to shorten
the care and maintenance time.
Fig. 118: TIC-Reactor
i
1
2
3
1 TIC-Reactor
2 TIC-Port
3 TIC-Stripping Vessel
