7 How to Work with the Analyser
7 How to Work with the Analyser
The following section gives an overview about the analyser‘s software and how to use it.
7.1 General
QuickTOC
®
ultra
is equipped with a touchscreen. You can either use a stylus or your fingers to operate
the software
7.1.1 User level
Classification of user levels and access permissions:
• User level 1
The user can view data (such as readings) but can not change anything in the system.
• User level 2
The user can view data (such as readings) and use functions described in this chapter.
• User level 3 (expert level)
The user can view data (such as readings) and perform functions described in this chapter. User
level 3 authorizes the execution of further functions, which are marked in the following with "user
level 3 only".
Warning
Damage to the touchscreen
The touch screen can be damaged by handling sharp objects. Operating er-
rors and illegibility can be the result.
Use only your fingers or stylus to operate the touch screen.
Notice
For user level 2 an access authorization with password can be set up
(Chapter 7.8.4 on page 123).
User level 3 (expert level) can only be activated via an authorized USB stick
from LAR.
To be able to use the functions of user level 3 (expert level), you must first
undergo training with LAR. If you are interested in this training, contact LAR
Technical Support (Chapter 15.1 on page 283).
!
i
