24 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
3 Product
3.4 Components of the Analyser LAR | PROCESS ANALYSERS AG
3.4.1.3 Sample Pump
The sample pump (Fig. 10) is used to transport the sample(s) for the TOC-difference and TConly meth-
ods. The number of sample pumps depends on the number of sample streams.
Fig. 10: Head of the sample pump (closed)
Danger
Danger of crushing
During operation, the rollers of the sample pump are in motion.
Do not reach into the working area of the sample pump during operation.
!
