LAR Process Analysers QuickTOC ultra - Start-Up of the CO2-Remover

232 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
9 Accessories and Options
9.5 CO2-Remover LAR | PROCESS ANALYSERS AG
9.5.4 Start-Up of the CO
2
-Remover
1. Connect all pipelines as shown in Fig. 149, page 232 to the CO
2
-Remover.
2. Connect the CO
2
-Remover to a suitable power source (100 - 240 V AC / 50 - 60 Hz).
3. Supply the CO
2
-Remover with suitable instrument air (in accordance to DIN ISO 8573-1) (4 to
12 bar and +1,5°C to +50°C).
1. Release the instrument air supply slowly until the CO
2
-Remover is under pressure.
2. Turn on the CO
2
-Remover to display its status and begin operation.
3. Let the CO
2
-Remover work for 2 cycles.
4. After the first 2 cycles, open the exhaust valve of the CO
2
-Remover.
Warning
Improper installation
Make sure that air can flow before the CO
2
-Remover is put into operation (tur-
ned on). If the air does not flow, there may be a desiccant contamination,
which means that the desiccant has to be replaced.
Fig. 149: Start-Up of the CO
2
-Remover
Warning
Improper installation
Ensure that the filter and pressure control unit is correctly connected to the
CO
2
-Remover unit.
!
!
