LAR Process Analysers QuickTOC ultra - Function Test Log (Analyser)

270 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
13 Operating, Care and Maintenance Logs
13.5 Function Test Log (Analyser) LAR | PROCESS ANALYSERS AG
13.5 Function Test Log (Analyser)
Visual Inspection Criteria OK Action
Check Analyser
• Zero signal is between
0 - 0.1 FSR
• Carrier Gas IN / OUT:
approx. 30 l/h
(high salt: approx. 20 l/h)

 Contact Support
__________________________
__________________________
__________________________
__________________________
Tightness Test
• Carrier gas volume flow
falls to < 5 l/h

 Contact Support
__________________________
Test Run (XY-System)
• All positions are hit by the
injection needle

 Contact Support
__________________________
Checking the
Measurement Results
• Measurement results
matches the calibration
standard

 Contact Support
__________________________
Checking the
Measurement Process
• Measurement Process
goes on without
complications

 Contact Support
__________________________
Date: Signature:
