8.6 Maintenance Actions
Use the following maintenance log for the documentation of maintenance actions:
Table 20: Maintenance log
Notice
A corresponding copy of the log can be found in Chapter 13 from page 265.
Careful documentation is a precondition for any guarantee and warranty
claims.
Action Done Comment
Interval: If necessary
Replace Supply Tubes 
Replace Inlet and Drain Tubes 
Replace Teflon Tube (Reactor Foot) 
Replace Reactor Pipe Filling / Reactor Pipe 
Replace Small Furnace Head Seal (upper) 
Replace Big Furnace Head Seal (Silicone O-Ring
with PFA coat)

Replace Injection Tube 
Replace Viton Tube 
Replace Acid Trap filling 
Replace Acid Trap 
Replace Quartz Wool Filter filling 
Replace Quartz Wool Filter 
Replace the scraper discs of the glass components 
Replace reactor foot seal 
Replace Injection Needle 
Interval: 1 Week
Replace Silicone Seal for TIC-Port

Interval: 1 Month
Replace Needle Guide Seal (Injection Port)

Interval: 6 Months
Replace Pump Tube (Tube Cassette Pump)

Replace Pump Tube (Sample Pump)

Date: Signature
