9.2 Reagent Cabinet LAR | PROCESS ANALYSERS AG
9.2 Reagent Cabinet
The reagent cabinet is used for the protected storage of the following reagents:
• Acid
• Rinsing Water
For the dimensions of the reagent cabinet, see chapter 11.3 on page 252.
9.2.1 Construction of the Reagent Cabinet
Notice
The containers for the reagents are delivered separately.
The reagent cabinet has different outputs for the solutions, which are labelled
specifically for the application. Please note the labelling.
Fig. 135: Reagent cabinet
i
1 Tube feedthroughs
2 Housing locks
1
2
