13 Operating, Care and Maintenance Logs
13.2 Visual Inspections Log (Analyser)
LAR | PROCESS ANALYSERS AG
13.2 Visual Inspections Log (Analyser)
Interval
Visual
Inspection
Criteria OK Action
1 Week
Zero Signal
• 0 - 0.1 FSR

 Check soda lime
 Contact support
Carrier Gas
• Carrier Gas IN / OUT:
approx. 30 l/h
(High Salt: approx. 20 l/h)

 Check connections
 Contact support
Injection System
• no air bubbles in the tube
or glass syringe

 Rinsing necessary
Injection Needle
• no contamination
• smooth surface

 Cleaning necessary
 Replace needle
Glass Components
• no contamination

 Cleaning necessary
Canisters and Supply
Tubes
• fill level > 1 litre
• no contamination
• normal elasticity

 Fill canister
 Clean canister
 Replace tube
Drain and Inlet Tubes
• no contamination
• normal elasticity

 Replace tube
_____________________
3 Months
Injection Tube
• no contamination
• normal elasticity

 Cleaning necessary
 Replace tube
TIC Stripping Vessel • no contamination

 Cleaning necessary
Slide Rails
(XY-System)
• no contamination
• optimal grease state
• mechanical play

 Cleaning necessary
 Grease necessary
 Contact support
Tube Cassette Pump
and Pump Tubes
• no moisture
• rolls easily movable
• no contamination
• normal elasticity

 Cleaning necessary
 Put forth tubes
 Replace tubes
 Contact support
Sample Pump and
Pump Tubes
• no contamination
• rolls easily movable

 Cleaning necessary
 Contact support
Viton Tubes
• no contamination
• normal elasticity

 Cleaning necessary
 Replace tubes
Filter Mats
• no discolouration

 Replace filter mats
Acid Trap
• zinc is > 1/3 shiny
• brass wool > 1/3 yellow

 Replace filling material
 Replace acid trap
Quartz Wool Filter
• no moisture
• no discolouration

 Replace filling material
 Replace filter
Date: Signature:
