12E5119 Instruction Manual QuickTOC
®
ultra
IECEx 49
4 Installation
4.1 Installation process
LAR | PROCESS ANALYSERS AG
Table 6: Installation log for optional accessories
Table 5: Installation log of the analyser
Task Criteria OK Comment
Ensure Environment
Conditions
• Dry and frost-proof
• Temperature: 5°C - 35°C
• Rel. humidity: < 80%
• No direct exposure to sunlight
• No aggressive environment
• No aggressive sample contents

Mounting and Installa-
tion of the Analyser on
Site
• Wall mounting:
Free space (W x H x D)
approx. 1,030 x 1,720 x 1,210 mm

• Mounting rack:
Free space (W x H x D)
approx. 1,070 x 2,000 x 1,420 mm

Provide Carrrier Gas
• Free of CO2, Carbon, Dust,
Water und Oil
• Pre pressure 2 - 3 bar
• Available in the direct vicinity

Provide Sample Inlet
• Depressurised
• Available in the direct vicinity

Provide Drain
• Depressurised
• Available in the direct vicinity

Provide Power Supply
• Mains voltage correct
• Power cable on power supply
connected

Install Signal
Connections
• Serial interface connected
• Digital Inputs connected
• Analog Outputs connected
• Relays connected

Provide Rinsing Water • Rinsing water provided

Provide Acid Solution • Acid solution provided

Provide Calibration
Standards
• Calibration Standard provided

Date: Signature:
Task Criteria OK Comment
Installation of Reagent
Cabinet
• Mounted on the wall, mounting
rack or placed under the
analyser

Installation of the
FlowSampler
®
• FlowSampler
®
mounted on the
wall to the right of the analyser

Date: Signature:
