9 Accessories and Options
9.6 Mounting Rack LAR | PROCESS ANALYSERS AG
The following installation dimensions must be observed:
min. 1,070 x 2,000 x 1,420 mm (W x H x D)
Recommendations for installation on the LAR mounting rack:
• The simplest method is to lay the analyser in the horizontal (flat) position after pre-assembly onto
the similarly horizontal LAR installation rack and secure it with four M8 bolts (M1 - M4). It is then
raised into the vertical position using lifting equipment (or a crane).
• In the second method, the analyser is mounted directly onto the vertical LAR rack using the M8
bolts. The weight of the analyser means lifting equipment or a forklift is required for this variant.
First, screw two bolts into the upper holes of the rack so they protrude by about 15 mm. Then
hook the analyser into these bolts with the mounting eyes, and lower it until the rear part of the
housing is resting against the rack. Then screw the bottom bolts through the mounting eyes into
the LAR rack, and tighten all the bolts.
Warning
The distance to side and opposing walls must be kept so that the analyser can
be swivelled open.
If you do not have access to a forklift or lifting equipment, the analyser should
be fitted by at least four people.
!
