20 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
3 Product
3.3 Construction of the Analyser LAR | PROCESS ANALYSERS AG
Bottom View of the Analyser (Example: TOC-Difference Method - 2 Sample Streams)
Fig. 6:
Danger
Risk of injury due to moving parts!
During operation the XY-system is moving.
Keep your hands and loose parts out of the area of the XY-system and the in-
jection needle.
Notice
A system key is included for peronell with authorisation.
Unauthorised personell are not permitted to open the front door of the housing.
Notice
The positioning of the vessels can differ depending on the number of sample
streams and the measurement method.
Furthermore, depending on the measurement method and number of samp-
les, there can be pump housings on the right-hand side of the analyser which
are used to transfer samples into the analyser.
!
i
i
