26 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
3 Product
3.4 Components of the Analyser LAR | PROCESS ANALYSERS AG
Notice
For an analyser with five sample streams, there is only one position left for ca-
libration vessel or rinsing vessel. This position may have to be swapped with
the calibration or rinse vessel depending on requirement. Only one place is
available for one of the vessels.
For an analyser with six sample streams, six sample vessels take up all the
space for vessels (V1-V6). For a calibration, the first vessel must be removed
from the position and be replaced by a calibration vessel. Before a calibration
can be performed, the positioning must be checked on the „Test Run“ display
(Chapter 7.2.13 from page 94). To rinse the injection needle, a sample vessel
must be defined, at best in one in which no repeat measurements take place
and preferably low concentrations are present.
i
