66 Instruction Manual QuickTOC
®
ultra
IECEx 12E5119
5 Start-up
5.8 Completion of the Furnace LAR | PROCESS ANALYSERS AG
Proceed as follows:
1. Place the furnace head (1) on the furnace (2) and on the furnace pipe (1, Fig. 39, page 63).
2. Connect the black tube (3) to the tube connector (4).
3. Tighten crosswise the attachment bolts (5) of the furnace head (1) with the furnace head panel (6).
4. Carefully tighten the injection port (7) by hand until slight resistance is felt (the injection port (7)
should point to the front left at an angle).
5. Plug in the injection port connector (8) .
6. Attach the reactor foot seating (9) to the reactor footplate (11) using three M4x30 bolts (10).
7. Connect the teflon tube (PFA) (12) to the screwed insert (13).
8. Screw the screwed insert into the reactor foot seating (10).
9. Plug the reactor foot onto the reactor pipe from below.
10. Screw on the four spacer bolts.
11. Pull the reactor foot down so that the gas path is not blocked by the reactor pipe.
12. Attach the bottom lid.
Notice
Before you fit the reactor foot, you should wait until the furnace has reached a tempe-
rature of 800°C. This simplifies the installation of the reactor foot.
i
