MAINTENANCE AND SERVICING
3. Close fuel supply v alve (A). Located on the bottom of
the fuel tank.
Figure 5.87: Bottom of Fuel Tank
4. Placea5U.S.gallon(20liter)drainpanunderthefuel
supply hose (A) at primary filte r.
5. Loosen clamp (B) and pull fuel supply hose (A)
off fitting.
Figure 5.88: Fuel System
6. Routehosetodrainpanandopenvalve(A)to
drain tank.
Figure 5.89: Fuel System
169890
2
42
Revision A
