MAINTENANCE AND SERVICING
1. Shut down engine and remove key. Turn beacons OFF.
NOTE:
Hold onto the handholds (B) on the cab front corners,
and stand on the header anti-slip strips, or stand on the
maintenance platform when accessing the beacons (A).
Figure 5.155: Warning Beacons
2. Turn lens (A) counterclockwise to unlock lens from
base and remove lens.
Figure 5.156: Warning Beacons
3. Pinch retainer (A) and remove it from lamp socket.
4. Pull lam p out of socket.
Figure 5.157: Beacon Lamp Assembly
169890 278 Revision A
