MAINTENANCE AN D SERVICING
5. Disconnect harness from lamp.
IMPORTAN T:
Do NOT touch the glass of the halogen bulb as the oils
or other chemicals from your skin will cause the bulb to
fail prematurely.
Figure 5.
158: Beacon Lamp Assembly
6. Connect harness to new lamp, place lamp in socket,
andlineuptheflat side on lamp with recess in socket.
Figure 5.159: Beacon Lamp Assembly
169890 279 Revision A
