DESCRIPTION
SYSTEM CAPACITIES
Fuel Tank
97 US Gallons (
367 L)
Cooling 6.6 US Gallons (25 L)
Hydraulic R eservo ir
11 .5 US Gallon s (44 L)
HEADER DRIVE
1
Single Piston Pump
(D)
1
Gear Pump
(B)
1
Gear Pump
(A)
1
Type
Hydraulic,
Load Sensing Control
Gear Gear
Displacement (manually adjusted
for header type and/or size)
0–3 cu. in. (49 cc) 1.02 cu. in. (16.7 cc) 1.02 cu. in. (16.7 cc)
Flow
0–30 gpm
(0–114 L/min)
0–11.5 gpm
(0–44 L/min)
0–11.5 gpm
(0–44 L/min)
Pressure
4000 psi (27,579 kPa) 2500 p si (17,237 kPa) 2500 psi (17,237 kPa)
Function
Knife
andBrake Charge
Reel Drive and
Supercharge for
Traction Drive
Convey
or (Draper,
Reel/
Auger- header
depen
dent)
HEADER LIFT/TILT Pump (C)
1
Type
Hydraulic Do ub le Acting Cylin de rs. Tilt - O p tio nal Hydraulic Positioning,
Optional Hydraulic Center-link
Displacement
1.0
2cu. in. (16.7cc)
Flow
0–11.5 gpm (44 L/min)
Gear Pump
System Pres sure
(Relief/Max)
2500 psi (17,237 kPa)
Function
L
ift/Tilt/Float
HEADER FLOTATION
Primary
Adjustment
Manual, External, Drawbolt With Springs (1 per side).
Inner Booster
Springs
Two
CAB
Mounting Type Rubber Isolation
Width 63 in. (1 60 0 mm)
Depth
68-1/3 in. (1735 mm) (at top of window)
Height
64.6 in. (1 64 0 mm)
Dimensions
Volume 125 cu. ft. (3540 L)
Driver
Adjustable Air-Ride Suspension, Seat Belt
Seat
Training
Folding, Cab Mounted, Seat Belt
Windshield Wiper 31-1/2 in. (800 mm) Blade
Heater
24,000 Btu/h (7038 W)
