DESCRIPTION
Air Conditioning 28,280 Btu/h (8288 W)
Electrical Ou
tlets
One Live, One o
n Ignition , One Live/K eyed
Mirrors
Two Outside (Field)
Radio
Two Speakers and Antenna Factory Installed. Radio Dealer Installed
SYSTEM MONI
TORING
Speeds
Ground (mph or km/h), Engine (rpm), Conveyor (Ref. No.), Knife (spm)
(Optional), Reel (rpm or mph/km/h) (Optional)
Header
Height, Angle (Optional)
TIRE OPTI
ONS, Refer to 2.1 Drive Tires, page 32
FRAME AND STRU CTURE
Dimensions
Refer to 2.3 Windrower Dimensions, page 3 2
Frame t
o Ground (Crop Clearance)
45-3/4
in. (1160 mm)
Base
8820 lbs (4000 kg)
2
Maximum GVW 17,750 lbs.(8050 kg)
Weight
Maxi
mum CGVW
20,2
00 lbs (9160 kg)
HEADER COMPATIBILITY
Aug
er
Hea
ders
A30
-D, A40-D
Compatible
Draper
Headers
D50, D60, D65 up
to 35 ft.
3
Compatible
NOTE:
Specifications and d esign are subject to change without notice or obligation to revise previously sold units.
1. Pump Orientation:
a. Gear pump (center). Draper control D-Series;
Reel/Auger control A-Series.
b. Gear pump (inboard). Reel control D-Series;
Reel/Auger control A-Series. Supercharge for
traction drive pumps.
c. Gear pump (outboard). Lift, Tilt, and Reel Fore-aft
circuits.
d. Single piston pump (closest to engine). Knife drive
and brake pressure.
e. Tandem piston pumps and traction drive.
Figure 2.1: Pump Orientation
2. Weights do not include options.
3. Depending on header options.
169890 31 Revision A
