Proceed as follows:
If the doors are not yet open, open them now:
To remove a light protection cover in the upper print unit; open all doors on
the left-hand side of the printing system.
To remove a light protection cover in the lower print unit; open all doors on
the right-hand side of the printing system.
3.
Caution
If a developer station is pulled out too quickly and suddenly, it may be pulled
out over the stop points and fall down.
Always pull a developer station out slowly and evenly to the stop point of the
guide rails. Take care not to stretch the toner hoses.
For all developer stations that are
below the light protection cover
to be removed:
■
Press the lock button.
■
Pull the developer station out
slowly and evenly as far as the
stop.
The developer stations must not
be removed.
4.
Chapter 6 - Operating the Printing System 195
Removing the Light Protection Cover
