Insertion of a Transfer Belt in the Upper Print Unit (Comple-
tion)
Attention:
Observe the safety directives in the ‘Replacing the Belt — Overview’ on page 350 section.
To Complete Insertion of a Transfer Belt in the Upper Print Unit
#
Proceed as follows:
Turn the belt tensioner 180° in
the direction of the arrow to the
stop point to tighten the transfer
belt.
1.
Caution
The device control checks the belt path of the transfer belt.
If the test run is not successful, the transfer belt was not pushed up to the
correct position. In this case, again:
■
Release the belt tensioner.
■
Move the transfer belt so that the control LED turns green.
■
Tighten the transfer belt.
Pull handle of the reload
corotron and swivel reload
corotron downwards.
2.
