Replacing the Transfer Belt in the Lower Print
Unit
Removing the Transfer Belt in the Lower Print Unit - Prepara-
tion
Attention:
Observe the safety directives in the ‘Replacing the Belt — Overview’ on page 350 section.
To Prepare to Remove a Transfer Belt in the Lower Print Unit
#
Proceed as follows:
If the printing system has not yet stopped, click the 'Stop' button.1.
On the operator panel, select the following menus and elements:
■
'Replace consumables' -> 'Replace belt' menu
■
'Select print unit': 'Lower print unit'
■
'Select assembly': 'Transfer unit'
■
'Select action to be executed': 'Replace belt'
■
Click the 'Next' button.
2.
Click the 'OK' button to start transfer belt replacement.
The replacement of the transfer belt is being prepared.
For information on the icons displayed on the operator panel under 'Steps': see
‘Explanation of icons’ on page 134.
3.
