Removing the cleaning corotron slide-in unit or charge
corotron slide-in unit of the photoconductor unit
Attention:
Observe the safety directives in the ‘Replacing the corotron — overview’ on page 412 section.
Note:
The procedure is the same for the upper and the lower print unit.
To Remove the Cleaning Corotron Slide-in Unit or Charge Corotron Slide-in Unit
of the Photoconductor Unit
#
Proceed as follows:
If the printing system has not yet stopped, click the 'Stop' button.1
On the operator panel, select the following menus and elements:
■
Menu 'Replace consumables' -> 'Replace corotrons'
■
'Select print unit': 'Upper print unit' or 'Lower print unit'
■
'Select assembly': 'Photoconductor unit'
■
'Select corotron': 'Cleaning' or 'Charge'
■
Click the 'Next' button.
2.
Click the 'OK' button to start corotron replacement.
Replacement of the corotron is being prepared. The developer stations are
swiveled off.
Information on the icons displayed on the operator panel under 'Steps': see
‘Explanation of icons’ on page 134.
3.
Caution
Wait until preparation is complete
The doors must not be opened before the relevant message is displayed on the
operator panel.
To remove a corotron slide-in unit in the upper print unit:
Open all doors on the right-hand side of the printing system.
4.
