Replacing the Belt
Replacing the Belt — Overview
Attention:
■
The photoconductor belt, photoconductor blade and transfer belt must only be used
for the intended purpose in each case.
■
The replacement must only be carried out by the operator after prior training or in-
struction by Service.
■
The replacement procedure can only take place when printing is stopped.
■
During replacement, always wear the gloves provided.
■
The surface of the photoconductor belt is extremely sensitive and can be easily damaged.
Avoid exposure to direct sunlight and do not touch.
■
The soft transfer belt is extremely sensitive to creasing and touch. Kinks and touching
the belt with hard objects should be strictly avoided.
The inner sliding surfaces of the slide foils must be clean. Dirt on the sliding surfaces
can damage the soft transfer belt.
■
If the life of the photoconductor belt, the photoconductor blade or the transfer belt
was very short, the cause of the damage must be clarified in order to prevent further
damage.
■
Store new photoconductor belts or transfer belts appropriately:
Do not store together with flammable substances.
Store in the closed original carton in a dry environment at 15 – 25°C.
Overview
The procedure for replacing a photoconductor belt and photoconductor blade is different
for the upper and lower print units:
Upper print unit:
■
‘Removing Photoconductor Belt in Upper Print Unit and Replacing Photoconductor Blade’
on page 352
■
‘Insert a photoconductor belt in the upper print unit’ on page 358
Lower print unit:
■
‘Removing Photoconductor Belt in Lower Print Unit and Replacing Photoconductor Blade.
’ on page 364
■
‘Inserting a Photoconductor Belt in the Lower Print Unit’ on page 370
