Oce ColorStream - Opening Left Doors

Opening Left Doors
To Open the Doors on the Left-Hand Side
#
Proceed as follows:
On the left-hand side of the
printing system, open the doors
as shown.
1.
Press the button at the bottom
right on the center cover.
2.
Pull the center cover forward on
the lower side and then lift up-
wards to remove.
3.
Chapter 6 - Operating the Printing System 161
Opening Left Doors
