Doors and Covers
Introduction
Note:
Right-hand side means right in paper path direction.
Left-hand side means left in paper path direction.
Right-Hand Side of Printing System
Left-Hand Side of Printing System
Legend
#
MeaningColor
These doors may be opened during printing without causing
any adverse effects. There is no danger, even if a door is open
Chapter 3 - Description of the Printing System54
Doors and Covers
