DescriptionComponent
Screen1
Keyboard and mouse2
Storage for the user guide3
Toner supply4
Toner hoses on the printing system5
Color Allocation in the Console
The developer stations for all colors are supplied by a toner suction system consisting of
toner bottles weighing 6 kg (13.2 lb) each. For full-color printing systems, the developer
station slots for CMYK are predefined. In order to keep the toner suction hoses as short
as possible, the slots in the console are also predefined:
Chapter 3 - Description of the Printing System62
Console
