Inserting the Transfer Belt in the Lower Print Unit
Attention:
Observe the safety directives in the ‘Replacing the Belt — Overview’ on page 350 section.
To Insert a Transfer Belt in the Lower Print Unit
#
Proceed as follows:
Caution
Note the belt type
Always reinsert a soft transfer belt (for order number see ‘Order Numbers and
Packaging Units for Expendables’ on page 349).
Open packaging of the new
transfer belt.
1.
Caution
Do not damage the surface of the transfer belt.
Wear the gloves provided in the packaging.
Remove transfer belt from the
packaging by the green tube.
One red tube is already in the
transfer belt, a second red tube
initially remains in the packag-
ing.
2.
