Proceed as follows:
Completely remove the soft
transfer belt:
■
First remove and hold onto
the green tube together with
the transfer belt.
■
Then loosen the other two
tubes. Leave the lower red
tube in the loop of the trans-
fer belt. Place the other red
tube on the outside.
■
Carefully roll the transfer belt
with the tubes into a bundle.
9.
Place the bundle to the side in the original packaging.10.
#
‘Inserting the Transfer Belt in the Lower Print Unit’ on page 402.11.
Chapter 9 - Replacing Expendables 401
Removing the Transfer Belt in the Lower Print Unit
