Proceed as follows:
Hold the insertion tool with
both hands and move the trans-
fer belt together with the sliding
foil evenly and carefully around
the roller until the sliding foil
wraps around the roller.
6.
Caution
The soft transfer belt is extremely sensitive to creasing and touch. Kinks and
touching the belt with hard objects should be strictly avoided.
Attach the three tubes from the
original packaging (green to
green/red to red) and evenly pull
the transfer belt together with
the insertion tool and sliding foil
out of the tube.
7.
Carefully loosen the insertion tool and sliding foils from the transfer belt and
set them to the side.
8.
Chapter 9 - Replacing Expendables400
Removing the Transfer Belt in the Lower Print Unit
