Proceed as follows:
Guide the insertion tool with the
sliding foil into the area of the
mark (white arrow). At the same
time, push the sliding foil careful-
ly between the transfer belt and
cover.
4.
Close the insertion tool and in-
sert it until the edge of the
transfer belt is between the four
embossing marks:
5.
Chapter 9 - Replacing Expendables 399
Removing the Transfer Belt in the Lower Print Unit
